NOVOTEST T-D3 – professional Leeb hardness tester
Applications
For inspection companies and manufacturers of large structures that need Leeb measurements with documentation, statistics and different probes (D, DC, DL, C, G, D+15, E) for various geometries and weights.
Key features
- Large colour display, modes: statistics, graph, histogram, Smart, Signal
- 88 material and scale combinations, 8 pre-calibrated materials
- Photo documentation, memory up to 32 GB, USB export
- Probes D (standard), DC, DL, C, G, D+15, E; DC-R, DC-R-mini options
- Waterproof housing with rubber bumper, wireless printer (option)
Models
T-D3; T-D3 (Lab)
Technical data
- Range (steel): HRC 20–70; HB 90–650; HV 230–940; Rm 370–1740 MPa
- Recommended part: >5 kg and >10 mm; surface Ra 3.2 and rougher
- Display: colour LCD 320 × 240; operating temperature -20…+40 °C
- Power supply: 3 × AA, ~10 h
- Dimensions / weight: 160 × 75 × 30 mm / ~0.3 kg (without probe)
Standards
ASTM A956, ASTM E140, ASTM A370, ISO 16859, DIN 50156, GB/T 17394, JB/T 9378, ISO 18265
What we offer
- Selection of the instrument and configuration for your task, together with the manufacturer
- Trial measurements of your samples in the manufacturer’s laboratory
- Training, calibration and service organised through the manufacturer
Technical data according to the manufacturer: novotest.biz
