NOVOTEST T-U2 – economical UCI hardness tester
Applications
For workshops and inspection departments that need an inexpensive portable instrument for small, thin-walled or complex-shaped parts (gears, bearings, welds, nitrided and carburised layers) where the Leeb method is not suitable.
Key features
- Smallest indentation among portable methods – suitable for hardened layers and coatings
- Parts from ~100 g and from 1 mm thick (thinner with the U1-TL stand)
- 10 N, 50 N, 98 N probes for different surface preparation
- Shock-resistant silicone housing, 2 × AA, ≥20 h of operation
- Upgradable to the combined T-UD2 by adding a Leeb probe (with an activation code)
- Lab version – Bluetooth connection to the NOVOTEST Lab app (Android)
Models
T-U2; T-U2 (Lab); Basic / Advanced 1–3 / Professional / Expert kits
Technical data
- Scales / ranges: HRC 20–70; HB 90–650; HV 100–750; Rm 370–1740 MPa; user calibrations
- Probe load: 10 N (1 kgf), 50 N (5 kgf), 98 N (10 kgf)
- Min. thickness / weight: 1 mm / 100 g
- Operating temperature: -20…+40 °C; power supply 2 × AA, ≥20 h
- Dimensions / weight: 122 × 65 × 23 mm / ≤0.2 kg
- Memory: 256 results; USB connection to PC
Standards
ASTM A1038
What we offer
- Selection of the instrument and configuration for your task, together with the manufacturer
- Trial measurements of your samples in the manufacturer’s laboratory
- Training, calibration and service organised through the manufacturer
Technical data according to the manufacturer: novotest.biz, novotest.biz
