NOVOTEST T-D2-R – Leeb hardness tester with miniature probe
Applications
For inspection in openings, grooves and between structural elements where a standard D probe does not fit. Minimal surface preparation, low sensitivity to grain structure.
Key features
- Miniature D1 dynamic DC-type probe in the standard kit
- Can be calibrated for any scale and range
- Memory for 256 results
- 2 × AA, ≥20 h of operation
- Operating temperature from -25 °C
Models
T-D2-R
Technical data
- Range: HRC 20–70; HB 90–650; HV 230–940
- Scales: HRC, HB, HV, HL
- Memory: 256 results
- Operating temperature: -25…+40 °C
- Dimensions / weight: 122 × 76 × 37 mm / ≤0.25 kg
Standards
ASTM A956, ASTM E140
What we offer
- Selection of the instrument and configuration for your task, together with the manufacturer
- Trial measurements of your samples in the manufacturer’s laboratory
- Training, calibration and service organised through the manufacturer
Technical data according to the manufacturer: novotest.biz
