Trimos V9 – highest-accuracy height gauge for the laboratory
Applications
For laboratories and workshops where measurement reliability is decisive. The V9 was designed without compromise on accuracy and repeatability – which is why some design details, especially the probe holders, differ from other models. The full touchscreen interface makes even complex tasks easier: programming, 2D mode, angle measurements and statistical analysis of results. The drive wheel allows a choice of manual or motorised movement.
Key features
- Measuring ranges 400–1100 mm
- Exceptional accuracy: BMPE 1.2 + L/1000 µm, repeatability 0.4 µm
- Electronically adjustable measuring force
- Manual or motorised drive
- 2D, programming, statistics
- Wide range of accessories, all adjustments without tools
- USB and RS232, wireless data transfer (optional)
Technical data
| Parameter | V9 400 | V9 700 | V9 1100 |
|---|---|---|---|
| Measuring range | 406 mm | 710 mm | 1109 mm |
| Range with extension | 724 mm | 1028 mm | 1427 mm |
| Maximum permissible error (BMPE) | 1.2 + L/1000 µm | 1.2 + L/1000 µm | 1.2 + L/1000 µm |
| Repeatability (2s) | 0.4 µm (Ø: 1 µm) | 0.4 µm (Ø: 1 µm) | 0.4 µm (Ø: 1 µm) |
| Perpendicularity deviation (SMPE) | 5 µm | 8 µm | 11 µm |
| Resolution | 0.0001 mm | 0.0001 mm | 0.0001 mm |
| Measuring force | 0.75–1.5 N | 0.75–1.5 N | 0.75–1.5 N |
| Battery life | 12 h | 12 h | 12 h |
| Air cushion | yes | yes | yes |
| Weight | 21 kg | 24 kg | 33 kg |
L – measured length, mm. Values determined according to ISO 13225 with the standard probe TA-MI-101.
What we offer
- Selection of the instrument and configuration for your task, together with the manufacturer
- Trial measurements of your parts in the manufacturer’s laboratory
- Training, calibration and service organised through the manufacturer
Technical data according to the manufacturer: trimos.com
