Trimos V4+ – height gauge with touchscreen and 2D measurements
Applications
For quality control and workshops that need the capabilities of a 2D height gauge at a more affordable price. The V4+ combines the reliable V4 mechanics with an advanced touch interface: distances, diameters and centre distances, a 2D view of the part with real-time results, and customisable measuring programs for complex measurements.
Key features
- Rigid mechanics – long and heavy probe tips up to 400 mm with excellent repeatability
- Dynamic graphical display of the measuring sequence and results
- Touch control and a clear menu structure – shorter training
- Integrated 2-coordinate measurement with 2D visualisation
- Integrated, customisable measuring programs
- Air cushion for easy movement on the surface plate
- USB, RS232 and wireless data transfer
Technical data
| Parameter | V4+ 400 | V4+ 700 |
|---|---|---|
| Measuring range | 407 mm | 711 mm |
| Application range | 719 mm | 1023 mm |
| Maximum permissible error (BMPE) | 2.5 + L/250 µm | 2.5 + L/250 µm |
| Repeatability (2s) | 2 µm (Ø: 3 µm) | 2 µm (Ø: 3 µm) |
| Perpendicularity deviation (SMPE) | 9 µm | 13 µm |
| Resolution | 0.001 mm | 0.001 mm |
| Measuring force | 0.75–1.5 N | 0.75–1.5 N |
| Battery life | 20 h | 20 h |
| Interfaces | USB / RS232 / wireless | USB / RS232 / wireless |
| Air cushion | yes | yes |
| Weight | 21 kg | 24 kg |
L – measured length, mm. Values determined according to ISO 13225 with probe tip TA-MI-101; RMPE – 2s of 20 height measurements.
What we offer
- Selection of the instrument and configuration for your task, together with the manufacturer
- Trial measurements of your parts in the manufacturer’s laboratory
- Training, calibration and service organised through the manufacturer
Technical data according to the manufacturer: trimos.com
