Trimos V2 – shop-floor height gauge with IP67 protection
Applications
For production shops that need a simple, durable and accurate height gauge for everyday measurement of heights, thicknesses and diameters. The user interface gives quick access to the main measurements, and the Smart Reverse function simplifies diameter measurement.
Key features
- Simple, intuitive interface
- Smart Reverse – convenient diameter measurement
- Measuring system protection class IP67 (CEI 60529)
- Electronically adjustable measuring force
- USB and RS232 for data transfer
- 400 and 700 mm models
- 2-year warranty, extendable to 4 years
Technical data
| Parameter | V2 400 | V2 700 |
|---|---|---|
| Measuring range | 406 mm | 710 mm |
| Maximum permissible error (BMPE) | 8 µm | 8 µm |
| Repeatability (RMPE) | 3 µm (Ø: 5 µm) | 3 µm (Ø: 5 µm) |
| Resolution | 0.001 mm | 0.001 mm |
| Measuring force (electronically adjustable) | 0.75–1.5 N | 0.75–1.5 N |
| Measuring system protection | IP67 | IP67 |
| Interfaces | USB / RS232 | USB / RS232 |
| Air cushion | no | no |
| Maximum manual travel speed | 1000 mm/s | 1000 mm/s |
| Operating temperature | +10…+40 °C | +10…+40 °C |
| Weight | 21 kg | 24 kg |
Values determined according to ISO 13225 with the standard measuring probe TA-MI-101. Repeatability (RMPE) – 2 standard deviations (2s) from 20 height measurements.
What we offer
- Selection of the instrument and configuration for your task, together with the manufacturer
- Trial measurements of your parts in the manufacturer’s laboratory
- Training, calibration and service organised through the manufacturer
Technical data according to the manufacturer: trimos.com
