Foerster TCM – modular mobile eddy current platform

Applications

For non-destructive testing on site and in production, when one inspector needs several eddy current methods: crack detection on rails, bridges and safety-critical parts, electrical conductivity measurement on aircraft structures, material verification and inspection of large surfaces. Instead of using a separate instrument for each task, the TCM is adapted by selecting the required app; the modules are purchased separately or together and can be added at any time, and software updates are free of charge.

App modules

• DEFECTOSCOP TCM – universal eddy current testing with rotating, high-frequency and low-frequency probes: crack detection and residual wall thickness measurement
• SIGMATEST TCM – electrical conductivity measurement of non-magnetic metals
• ECA TCM – inspection of large areas with eddy current arrays of up to 512 channels
• ECMEASURE TCM – measurements trained on reference samples, e.g. coating thickness, ferrite content, residual wall thickness

Key features

• One instrument – several methods, a uniform interface and data logic
• Automatic probe recognition, user roles, context-sensitive help
• Works with FOERSTER probes and probes from other manufacturers
• Raw data, screenshots and automatic Word / PDF reports
• Windows 10 LTSC – IT integration, remote support, external displays

Technical data

What we offer

• Selection of the instrument and configuration for your task, together with the manufacturer
• Trial measurements of your parts in the manufacturer’s laboratory
• Training, calibration and service organised through the manufacturer

Request a quote

Technical data according to the manufacturer: foerstergroup.com
