Sylvac S_Cal EVO Form B / Form E – mid-size calipers 300–500 mm

Applications

For larger parts, when a 300 mm pocket caliper is not enough or internal dimensions have to be measured with the upper jaws (r5). Form E – the same design without upper jaws.

Key features

  • Integrated Bluetooth® data transfer; programmable button.
  • IP67 protection for work with coolants.
  • Upper jaws r5 for internal and external measurements (Form B).
  • 16 × 6 mm beam section – rigid frame; SIS technology.
  • Max. speed 2.5 m/s.

Models

Model Range Resolution Protection Connectivity
810-1557 (Form B) 300 mm 0.01 mm IP67 Bluetooth®
810-1559 (Form B) 500 mm 0.01 mm IP67 Bluetooth®
Form E (mid-size r5)

Technical data

  • Maximum permissible error, external: ±30 µm (300 mm; ±20 µm up to 50 mm), ±50 µm (500 mm) – ISO 13385-1.
  • Maximum permissible error, internal: ±50 µm (300 mm), ±70 µm (500 mm).
  • Dimensions A/B/C/D: 300 mm – 410/100/20/5 mm; 500 mm – 625/120/23/7.5 mm.
  • Power supply: lithium CR2032.

What we offer

  • Selection of the instrument and configuration for your task, together with the manufacturer
  • Trial measurements of your samples in the manufacturer’s laboratory
  • Training, calibration and service organised through the manufacturer

Request a quote

Technical data according to the manufacturer: sylvac.ch, sylvac.ch
